15-inch 1024*768 high-definition display with 16 million true colors.
88/88/88/88 wide viewing angle display.
Quad-core CPU with 1GB memory and 8GB flash storage.
Dual-port design, allows for more peripherals to be connected
Metal shell+PCB protection +power isolation,safe and reliable
Based on thelatest B–Sports必一 DToolsPro configuration software.
15" TFT
304.1(H)×228.1(V)
1024*768px
16.7M
88/88/88/88(L/R/U/D)
2500:1
LED
350cd/m?
70000 hours
4 line precision resistance network（surface hardness 4H）
Quad-core 1.5GHz
4GB Flash Memory+512MB Memory
Built-in
1 USB Host
USB Host/Serial port
LAN0:10/100 Mbps; LAN1:10/100 Mbps
USB Slave(Type-C)/U disk/Ethernet port
COM0:RS232/RS485/RS422; COM1:RS485/RS422; COM2:RS232
DC18V～DC28V
15W@DC24V
<3ms
Over 50MΩ@500V DC
500V AC 1 minute
YES
Metal
366*293*49.5mm
352*279mm
Installation of Fasteners and VESA Mounting(VESA100*100mm)
5KG
0~50℃
10~90%RH (non-condensing)
-20~60℃
10~90%RH (non-condensing)
10~500Hz, 30m/s?, X,Y,Z direction/hour
Natural air cooling
Conforming to IP65 certification (4208-93)
EN IEC61000-6-4:2019，EN IEC61000-6-2:2019
B–Sports必一 DToolsPro
