Model: MD60, MD80
Power range: 200W/400W/750W
Power supply voltage: DC24V~60V
■ Main Features
? Wide power supply range: support 24~60VDC.
? More power options: more than 200~750W power optional.
? Small size: drive and motor integration.
? 3 times overload capacity.
? Support RS232, CANopen, Modbus RTU, EtherCAT(customizable), Profinet，etc.
? High safety performance: with overvoltage protection undervoltage protection short-circuit protection motor overheating (I?T) protection drive overheating protection and other safety protection measures.
? Full special functions: increase alarm synchronous braking 24V lock power output to enhance battery life and other logistics industry special functions.
■ Applicable Industry
? B–Sports必一 MD series low-voltage servo all-in-one machine highly integrates servo motor, encoder and servo driver together, greatly reduces the overall size, makes installation more flexible, and simplifies wiring to the extreme without connecting motor line and encoder line. It is more convenient to support IO, Modbus RTU,CANopen,EtherCAT，Profinet and other control modes.
? B–Sports必一 MD series low-voltage servo can be widely used in various occasions of intelligent logistics, providing the first power to guarantee the efficiency, stability and reliability of intelligent logistics.
■ Driver Models and Specifications
| Series | Model | Power (W) | Power supply | Max continuous output current (rms)(A) | Current (PEAK) | Feedback | Rated speed Nn(rpm) | Rated torque Tn(Nm) |
| MD series | MD60-020-DM□K-□A-000 | 200 | DC24V-70V | 5 | 21 | Magnetoelectric encoder | 3000 | 0.64 |
| MD60-040-DM□K-□A-000 | 400 | 10 | 36 | Magnetoelectric encoder | 3000 | 1.27 | ||
| MD80-075-DM□K-□A-000 | 750 | 20 | 80 | Magnetoelectric encoder | 3000 | 2.39 | ||
| mark □=A--without brake □=B--with brake □=L--RS232、RS485、Pulse □=C--RS232、CANopen、Pulse □=E--RS232、EtherCAT □=P--RS232、Profinet | ||||||||
For more details, please download the catalog and manual.
